Crown Micro Xavier X-3KW-PF1 MPPT Solar Inverter
Original price was: 52,000.00৳ .45,000.00৳ Current price is: 45,000.00৳ .
- Model: X-3KW-PF1 (PV-3000)
- Pure sine wave inverter with built-in 100A MPPT (60–400VDC, 450V OCV)
- Works with or without battery; 24V Lithium/Lead-acid supported; built-in Wi-Fi
- Output PF=1, peak efficiency 93%, surge 6000VA, 2.5″ LCD (touch), anti-dust kit
- 4-year warranty (terms & conditions apply)
Genuine Product
Everything is authentic
Installation Support
Expert installation support
Crown Micro Xavier X-3KW-PF1 (PV-3000)
Crown Micro Xavier X-3KW-PF1 PV-3000 is a 3kW pure sine wave, MPPT-based solar inverter built for reliable home and SME power. It combines a wide PV input window (60–400VDC, 450V OCV) with an integrated 100A MPPT solar charger, flexible AC input ranges, and a fast 10ms transfer time for sensitive loads. The inverter supports 24V Lithium or Lead-acid batteries, yet can also operate without a battery when required. With 93% peak efficiency, 6000VA surge, a 2.5″ LCD touch display, anti-dust kit and built-in Wi-Fi, it’s a capable and user-friendly choice for off-grid and backup applications.
Technical Specifications
| Category | Specification |
|---|---|
| Model Name | X-3KW-PF1 (PV-3000) |
| Rated Power | 3000VA / 3000W |
| INPUT | |
| Voltage | 230VAC |
| Selectable Voltage Range | 170–280VAC (for PCs) / 90–280VAC (for home appliances) |
| Frequency Range | 50Hz / 60Hz (auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Battery Mode) | 230VAC ±5% |
| Output Power | 3000W |
| Surge Power | 6000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10ms (for personal computers) |
| Waveform | Pure sine wave |
| BATTERY | |
| Battery Voltage | 24VDC |
| Floating Charge Voltage | 27VDC |
| Overcharge Protection | 32VDC |
| Battery Type | Lithium / Lead-acid |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Max PV Array Open-Circuit Voltage | 450VDC |
| Max PV Array Power | 4000W |
| MPPT Range @ Operating Voltage | 60–400VDC |
| Max Solar Charge Current | 100A |
| Max AC Charge Current | 80A |
| Max Charge Current | 100A |
| GENERAL SPECIFICATIONS | |
| Dimensions (D×W×H) | 100 × 283 × 390 mm |
| Net Weight | 7.5 kg |
| Communication Interface | RS232 |
| OPERATING ENVIRONMENT | |
| Humidity | 5%–95% RH (non-condensing) |
| Operating Temperature | −10°C to +50°C |
| Storage Temperature | −15°C to +60°C |
