    Crown Micro Arceus-3.6KW 24V PV-5000W MPPT Solar Inverter

    Original price was: 47,500.00৳ .Current price is: 44,500.00৳ .

    Brand: Crown Micro
    • Model: ARCEUS-3.6KW
    • Pure sine wave MPPT inverter
    • Dual output load management
    • Built-in Wi-Fi (Optional) & BMS system
    • Works without battery option
    • Feed-in to grid supported
    • 4-year warranty (terms & conditions apply)
    Add to wishlist
    Compare

    Genuine Product

    Everything is authentic

    Installation Support

    Expert installation support

    The Crown Micro ARCEUS-3.6KW 24V PV-5000W inverter is a high-performance pure sine wave solar inverter with integrated MPPT technology. Designed for flexible residential and commercial use, it supports both grid-tied and off-grid applications, with or without batteries. Built-in Wi-Fi (Optional), advanced BMS, and multiple protection features ensure reliable and efficient solar power conversion.

    Key Benefits

    • Pure sine wave MPPT inverter with high efficiency of 93.5%.
    • Wide MPPT voltage range (40VDC – 450VDC) for versatile solar setups.
    • Dual output for smart load management and priority power supply.
    • Compatible with AC mains or generator input for backup solutions.
    • Advanced protection against overload, short-circuit, and DC faults.
    • Built-in Wi-Fi (Optional) and BMS for monitoring and intelligent system control.

    For best performance, pair this inverter with high-efficiency solar panels and a reliable battery bank, ensuring long-term stability and power security.

    Technical Specifications

    Parameter Value
    Model Name ARCEUS-3.6KW
    Rated Power 3600VA / 3600W
    AC Input Voltage 220 / 230 / 240 VAC ± 3%
    Voltage Range 90–280VAC (single phase)
    Output Power Factor 1.0
    Waveform Pure sine wave
    Max. Efficiency (Peak) 93.5%
    Charger Type MPPT
    Max PV Input Power 5000W
    PV Voltage Range 40–450VDC
    Max PV Input Current 18A
    Battery Voltage 24VDC
    Battery Type Lithium / Lead-acid
    Display 5.2” LCD, multifunction
    Communication RS485 / CAN / USB / Wi-Fi (Optional)
    Dimension (W*H*D) 312*430*120 mm
    Net Weight 7.8 kg
    Operating Temp. 0°C to 40°C
    Storage Temp. -15°C to 60°C
