Solis IntelliHome-5kWh-OD 51.2V 100Ah Lithium Solar Battery
Original price was: 145,000.00৳ .128,000.00৳ Current price is: 128,000.00৳ .
- Model: IntelliHome-5kWh-OD
- Battery Type: LiFePO4
- Rated Capacity: 100Ah, Cycle Life: ≥6000
- Nominal Energy: 2.56kWh, Voltage: 51.2V
- Max. Charge Current: 50A, Max. Discharge Current: 100A
- Supports 8 units in parallel (40kWh max)
- 10-year warranty (terms & conditions apply)
Genuine Product
Everything is authentic
Installation Support
Expert installation support
The Solis IntelliHome-5kWh-OD 51.2V 100Ah Solar Battery is an advanced Solar Battery designed for residential and commercial solar energy storage systems. This 5kWh LiFePO4 Battery features a 51.2V nominal voltage and 100Ah capacity. With a maximum 100% depth of discharge (DOD), it provides access to its full rated energy capacity. Its lithium iron phosphate chemistry offers enhanced thermal stability, improved safety, and an extended cycle life. This Inverter Battery supports efficient energy storage with compatible solar power systems.
The Solis IntelliHome-5kWh-OD LiFePO4 Battery features an IP66-rated enclosure and C5M corrosion protection for demanding outdoor environments. Its integrated battery management system (BMS) monitors battery operation and supports CAN and RS485 communication. These interfaces enable communication with compatible inverters and parallel battery systems. Natural convection cooling supports quiet operation without active cooling fans. This Lithium Battery offers wall-mounted and floor-standing installation options for suitable residential and commercial applications.
With over 6,000 charge cycles and a specified service life of up to 10 years, the Solis IntelliHome-5kWh-OD 100AH battery supports long-term solar energy storage. Its intelligent heating function enables charging at temperatures as low as -20°C. The battery supports a continuous charging current of 50A and a continuous discharge current of 100A. Users can connect up to eight units in parallel, expanding total storage capacity to 40kWh. This scalable Solar Battery helps accommodate increasing energy storage requirements.
The Solis IntelliHome-5kWh-OD 51.2V Inverter Battery measures 470 × 650 × 150mm and weighs 50kg. It operates within an ambient temperature range of -20°C to 55°C, subject to specified temperature-related derating. The battery meets several recognized safety and transportation standards, including IEC 62619 and UN 38.3. It supports selected Solis inverters, so compatibility should be confirmed before installation. For customers seeking a durable Lithium Battery, this 100AH battery offers expandable capacity, intelligent battery management, and reliable energy storage for compatible solar installations.
The SolisStorage IntelliHome-5kWh-OD 51.2V 100Ah 5kWh LiFePO4 Battery offers broad inverter compatibility through RS485 and CAN communication. It works seamlessly with leading inverters brands including Growatt, Deye, GoodWe, SMA, Solis, Sofar Solar, Victron Energy, LuxPowerTek, SRNE, and Voltronic Power for reliable solar energy storage applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Performance Parameters | |
| Cell Type | LiFePO4 |
| Rated Energy | 5.0 kWh |
| Series And Parallel Connections | 1P16S |
| Nominal Voltage | DC 51.2V |
| Operating Voltage | DC 44.8 – 57.6V |
| Rated Capacity | 100Ah |
| Recommended Charge & Discharge Rate | 0.5C |
| Recommended Charge & Discharge Current | DC 50A |
| Maximum Continuous Charging Current | DC 50A |
| Maximum Continuous Discharge Current | DC 100A |
| Peak Charge/Discharge Current (@25°C, 10s) | DC 75A/150A |
| Peak Charge/Discharge Current (@25°C, 12s) | DC 65A/130A |
| Operating Ambient Temperature For Charging | -20~55°C (with heating function)(>45°C, derating) |
| Operating Ambient Temperature For Discharging | -20~55°C (>45°C, derating) |
| Communication Port (Between Parallel Battery Systems) | RS485 channel |
| Communication Port (Between PCS And Battery System) | CAN channel |
| Cycle Life | >6000 Cycles / 10 Years |
| Depth of Discharge (DOD) | Max. 100% DOD |
| Expansion Capability | Up to 8 units in parallel |
| Standard Parameters | |
| Cooling Method | Natural Cooling |
| Certifications & Safety Standards | IEC 62619, IEC 63056, ISO13849, VDE 2510-50, UN 38.3, EN/IEC61000-6-1/2/3/4, IEC 60730-1, IEC 60529 (IP) |
| Compatible Inverters | S6-EH1P(3-6)K-L-EU/S5-EH1P(3-6)K-L(Smart)/S6-EH1P(3-10)K-L-PLUS/S6-EH1P(9.9-18)K03-NV-YD-L/S6-EH2P(5-8)K02-SV-YD-L/S6-EH2P(9.6-16)K03-SV-YD-L-US/S6-EH3P(8-18)K02-NV-YD-L/S6-EH3P(7-10)K02-LV-YD-L/SS-EA1P3K-L/S6-EA1P(3.6-6)K-L/S6-E01P(4-6)K-48/S6-E01P(4-5)K-48-EU |
| Dimensions [W×H×D] | 470 × 650 × 150 mm |
| Weight | 50kg |
| Protection Level Ingress Protection | IP66 |
| Anti-corrosion Class | C5M |
| Pollution Levels | IEC60664-1 Level III |
| Protection Class | Class I |
| Mounting | Floor-mounted / Wall-mounted (default) |
| Environmental Protection Standards | ROHS, Reach |
| UN Transportation Test Standard | Shipping, Land transportation |
| Recommended Operating Temperature | 10~45°C |
| Maximum Operating Altitude | ≤4000m (>2000m, derating) |
| Operating Ambient Humidity | 5~95%RH |
| Noise Level | ≤30db |
Test conditions: @25°C, 0.5C/0.5C, 70% EOL @ 100% DOD
Protection Features
- Over/Under Voltage Protection: Yes
- Over Current Protection: Yes
- Over/Under Temperature Protection: Yes
- DC Breaker: Yes
- DC Overcurrent Fuses: Yes
- Aerogel Thermal Insulation Plate: Yes
- Fire Protection Function: Yes
- Explosion Release Valves: Yes
