LVTOPSUN 51.2V 100Ah 5.12kWh Lithium Iron Phosphate Battery

LVTOPSUN LVTS-512100-NS 5.12kWh LiFePO4 Battery is a high-capacity, wall-mounted lithium power storage solution designed for solar, IPS, and UPS systems. Featuring advanced BMS protection, long cycle life, fast charging, and maintenance-free operation, it delivers safe, efficient, and reliable backup power for residential and commercial use.

The LVTS-512100-NS is a state‑of‑the‑art lithium‑ion battery that has been meticulously developed to meet the energy demands of residential photovoltaic systems. Its design emphasizes straightforward installation and seamless integration, making it an attractive option for homeowners who aspire to maximize their solar power investment.

One of the most compelling features of the LVTS-512100-NS is its intuitive installation process. The unit is designed with flexible mounting options that allow for both wall and floor placement, enabling installers to choose the most practical configuration for a given space. With pre‑configured connection points and a streamlined setup protocol, the LVTS-512100-NS significantly cuts down on installation time, ensuring that your energy storage system is up and running swiftly and safely.

Technical Specification

• System Voltage : 51.2 V
• Output Power Range : 0-5 kWh
• Grid connection : Off grid, Hybrid grid
• Battery Type : LiFePO4
• Place of Origin : Guangdong, China
• System Type : Wall-Mounted
• Model Number : LV-512100-NS
• Brand Name : LVTOPSUN
• Dimension (L*W*H) : 440x500x132 mm
• Weight : 48 kg
• Type : Split
• Communication Port : CAN, RS-232, Rs485
• Battery type : Lifepo4/lithium Battery
• Capacity : 100 Ah
• Nominal Voltage : 51.2 Vdc
• Warranty : 6 years
• Discharge Current : 100 A
• Dimension : 440x500x132 mm
• Cycle life : 6000 Cycles @ 90% DOD/25°C/0.5C,60% EOL
• Working temperature : -20℃ – 60℃
• Installation : Rack mounted or wall mounted
• IP rating : IP20
